We use the most technologically advanced carbon construction available to make the most sophisticated frame possible – A complex and painstaking process with results you will appreciate in the saddle.
ORBEA ROAD RACING GEOMETRY
Orca Racing Geometry is born from almost 100 years of designing road racing bikes and is the perfect balance of responsiveness and stability. The position is aggressive to maximize body aerodynamics and efficiency. Handling is precise and intuitive. Angles and dimensions are considered carefully across a range of sizes to put more power to the road with every pedal stroke, and more power means more speed.
ADAPTABLE ERGONOMICS
How can ergonomics help you ride further? Unlike a racing position that is focused on aerodynamics, an endurance position results in a bike that is easier to ride and increases stamina. A shorter cockpit and higher handlebar maximize rider comfort – and more comfort means longer and faster rides.
Specifications
|
Frame |
Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible. |
|
Fork |
Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout. |
|
Crankset |
Shimano Ultegra R8100 36x52t |
|
Headset |
FSA 1-1/2" Integrated Aluminium Cup |
|
Handlebar |
OC RA10 Road Aero Carbon, Reach 80, Drop 125, Flare 5, w/Di2 hole |
|
Stem |
OC Road Performance RP10 Stem, -8º, IFC02 Computer Mount Performance |
|
Shifters |
Shimano ST-8020 |
|
Brakes |
Shimano R8070 Hydraulic Disc |
|
Cassette |
Shimano Ultegra R8000 11-30t 11-Speed |
|
Rear derailleur |
Shimano Ultegra R8000 SS |
|
Front derailleur |
Shimano Ultegra R8000 |
|
Chain |
KMC X11-EL |
|
Wheels |
FULCRUM Racing 400 DB |
|
Tyres |
Vittoria Rubino Pro IV G2.0 700x25c |
|
Seatpost |
Orbea Orca Aero OMX, SB0/25, w/Micro tilt adjustment |
|
Saddle |
Prologo Dimension T4.0 size143 mm |
|
Handlebar Plugs |
Orbea Anti-Slippery/Shock Proof |
|
Front Wheel Axle |
Orbea Thru Axle 12x100mm M12x2 P1 Lite |
|
Rear Wheel Axle |
Orbea Thru Axle 12x142mm M12x2 P1 Lite |
|
Hydration |
Orbea Aero Bottle and Bottle cage Set |
|
Storage |
Aero Accessory Container |
