Geometry
Every good bike fit starts with choosing the correct frame size for you. This will allow you to benefit best of the bike’s performance and comfort for an efficient riding position.
| 45 | 48 | 51 | 53 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|---|
| Seat Tube (A1) | 420 mm | 455 mm | 485 mm | 505 mm | 535 mm | 550 mm | 580 mm |
| Top Tube (B) | 505 mm | 515 mm | 530 mm | 546 mm | 560 mm | 575 mm | 590 mm |
| Reach (R) | 370 mm | 375 mm | 380 mm | 385 mm | 387 mm | 389 mm | 390 mm |
| Stack (S) | 520 mm | 521 mm | 547 mm | 560 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle (C) | 75,5° | 75° | 74,7° | 74° | 73,5° | 73° | 72,5° |
| Steering Tube Angle (D) | 71,2° | 71,5° | 72° | 72,5° | 73° | 73,5° | 74° |
| Chain-Stay (E) | 406 mm | 406 mm | 406 mm | 406 mm | 408 mm | 412 mm | 412 mm |
| Chain-Stay (F) | 575 mm | 578 mm | 586 mm | 591 mm | 594 mm | 599 mm | 602 mm |
| Headtube (H) | 115 mm | 115 mm | 140 mm | 152 mm | 170 mm | 194 mm | 218 mm |
| Wheelbase WB) | 971 mm | 974 mm | 982 mm | 987 mm | 991 mm | 999 mm | 1002 mm |
| (S')Sloping | 114 mm | 82 mm | 79 mm | 75 mm | 71 mm | 83 mm | 80 mm |
| Stand Over | 722 mm | 744 mm | 772 mm | 789 mm | 810 mm | 830 mm | 857 mm |
